Sample Cooler SC10
Price range: $569.33 through $1,997.33
• Same as SC108 but with a fully 304SS shell—perfect when you need a fully corrosion-resistant high-pressure cooler in a very small footprint.
Sample Cooler SC10 — Type 2 (Larger, More Cost-Effective)
A fully 304SS shell sample cooler, perfect for corrosion-resistant high-pressure cooling in a compact footprint. Suited for food-grade or highly corrosive fluid sampling at extremely high temperatures and pressures.
Specifications
| Coil Material | 316 Stainless Steel |
| Maximum Coil Pressure | 4,925 PSI @ 1,000°F |
| Coil Surface Area | 3/8" OD – 1.9 sq. ft. |
| Shell Material | 304 Stainless Steel (304SS) |
| Overall Height | 15.75" |
| Weight | 30 lbs |
Connections
| Sample Inlet (top plate) | 1/4" FNPT |
| Cooling-Water Inlet (top plate) | 3/8" FNPT |
| Cooling-Water Outlet (bottom plate) | 3/8" FNPT |
| Cooled Sample Exit | Bottom fitting |
Typical Applications
- Labs or pilot plants requiring worst-case pressure and corrosion resistance
- Food-grade or highly corrosive fluid sampling
- High-temperature/high-pressure compact cooler installations
| Weight | N/A |
|---|---|
| Brand | Madden Engineered Products |
| Configuration | 1, 2, 2A, 3, 5, 5A, 6, 6A, 7, 7A, 8, 8A |
