Sample Cooler SC000
Price range: $625.33 through $1,320.67
• Grab or small-volume continuous sampling in tight spaces (unit is under 18″ tall). • Laboratory or field use where you want to drop a hot sample into a chilled coil and collect it immediately below.
Sample Cooler SC000
Specifications
| Type | 1 (Compact) |
| Coil Material | Copper |
| Maximum Coil Pressure | 300 PSI @ 400°F |
| Coil Surface Area | 1/4" OD – 1.3 sq. ft. |
| Shell & Cap Material | Carbon Steel (CS) & Cast Iron (CI) |
| Overall Height | 18-3/16" |
| Shell Diameter | 3-1/2" |
| Sample Connection | 1/4" FNPT |
| Cooling Water Connections | 3/4" FNPT |
| Drain | 3/4" FNPT |
| Weight | 12 lbs |
Applications
Designed for cooling boiler water, steam condensate, and other hot fluid samples to a safe handling temperature for analysis and testing.
Note: We will contact you during order fulfilment to discuss shipping and handling costs for products weighing more than 150 pounds. These costs will be billed separately.
| Weight | N/A |
|---|---|
| Brand | Madden Engineered Products |
| Configuration | 1, 2, 3, 3A, 4, 4A |
